Operating Mode
The WAP6910 uses an integrated multi-mode design to flexibly switch Operating Mode based on requirements, reducing deployment cost.
Fat AP: The WAP6910 supports Fat AP mode, allowing the AP to operate independently without a wireless controller. Ideal for small networks such as homes and temporary venues, users can flexibly choose installation locations and deploy quickly without complex planning or additional equipment.
Fit AP: The WAP6910 supports Fit AP mode and works with a wireless controller for batch AP deployment and large-scale wireless networking with centralized AP management. Suitable for conference rooms, campuses, hospitals, and similar scenarios with batch deployment, seamless roaming, and unified security policies.
Wireless features.
Dual-band 8 SSIDs (4 on 2.4 GHz and 4 on 5 GHz), supporting Chinese SSIDs, hidden SSIDs, MAC whitelists, and band steering (5 GHz preferred).
Encryption: OPEN, WPA/WPA2-PSK (TKIP/AES), WPA3-PSK (AES).
Enterprise features: QoS (WMM), client isolation, client count limits, DHCP service, firewall, and PPPoE dial-up.
WiFi scheduled shutdown for energy savings and improved security.
Network scalability.
Supports built-in/external DHCP servers and cloud platform integration for large-scale networking.
One gigabit LAN port and one 2.5 GE WAN port for multi-device access.
Convenient management features.
One-touch reset: press and hold Reset for 6–10 seconds to restore factory defaults.
Remote management: firmware upgrade, configuration backup/restore, scheduled reboot, and system logs.
Status visualization: real-time display of wireless rate, uptime, device information, and other key data.
Protection capability.
IP67 rating (dust and water resistant) for outdoor deployment.
Lightning protection board component enhances surge resistance.
ESD protection: air discharge ±8 kV, contact discharge ±6 kV.
Surge protection: common mode 4 kV, differential mode 2 kV.
表1产品规格
属性 | WAP6910 | ||||
尺寸 | 304mm × 181mm × 88mm | ||||
以太网接口 | WAN：1 x 10/100/1000/2500 Mbps auto-negotiation WAN port,SupportsPoE 48V Power supply； | ||||
2.4 GHz operating band | 2.4GHz～2.484GHz | ||||
2.4G WIFI传输协议 | 802.11b/g/n/ax | ||||
5 GHz operating band | 5.150GHz～5.850GHz | ||||
5G WIFI传输协议 | 802.11a/n/ac/ax | ||||
Maximum rate | 2.4 GHz up to 574 Mbps; 5 GHz up to 2402 Mbps. | ||||
Maximum wireless clients | 256 | ||||
POE | 802.3at | ||||
Built-in antenna | 2 x 2.4G/5G antennas, 5 dBi gain each 2 x 5G antennas, 6 dBi gain each | ||||
2.4G transmit power | 802.11b | 11M | 26±2dBm | 1M | 26±2dBm |
802.11g | 54M | 23±2dBm | 6M | 25±2dBm | |
802.11n HT20 | MCS7 | 22±2dBm | MCS0 | 24±2dBm | |
802.11n HT40 | MCS7 | 22±2dBm | MCS0 | 24±2dBm | |
802.11ax HE20 | MCS11 | 20±2dBm | MCS0 | 24±2dBm | |
802.11ax HE40 | MCS11 | 20±2dBm | MCS0 | 24±2dBm | |
5G transmit power | 802.11a | 54M | 22±2dBm | 6M | 25±2dBm |
802.11n HT20 | MCS7 | 21±2dBm | MCS0 | 23±2dBm | |
802.11n HT40 | MCS7 | 21±2dBm | MCS0 | 23±2dBm | |
802.11ac VHT20 | MCS9 | 21±2dBm | MCS0 | 23±2dBm | |
802.11ac VHT40 | MCS9 | 20±2dBm | MCS0 | 23±2dBm | |
802.11ac VHT80 | MCS9 | 20±2dBm | MCS0 | 23±2dBm | |
802.11ax HE20 | MCS11 | 20±2dBm | MCS0 | 22±2dBm | |
802.11ax HE40 | MCS11 | 20±2dBm | MCS0 | 22±2dBm | |
802.11ax HE80 | MCS11 | 20±2dBm | MCS0 | 22±2dBm | |
802.11ax HE160 | MCS11 | 20±2dBm | MCS0 | 22±2dBm | |
2.4G receive sensitivity | 802.11b | 11M | -87dBm | 1M | -94dBm |
802.11g | 54M | -75dBm | 6M | -88dBm | |
802.11n HT20 | MCS7 | -72dBm | MCS0 | -88dBm | |
802.11n HT40 | MCS7 | -70dBm | MCS0 | -88dBm | |
802.11ax HE20 | MCS11 | -63dBm | MCS0 | -88dBm | |
802.11ax HE40 | MCS11 | -61dBm | MCS0 | -88dBm | |
5G receive sensitivity | 802.11a | 54M | -75dBm | 6M | -90dBm |
802.11n HT20 | MCS7 | -73dBm | MCS0 | -88dBm | |
802.11n HT40 | MCS7 | -63dBm | MCS0 | -88dBm | |
802.11ac VHT20 | MCS8 | -67dBm | MCS0 | -88dBm | |
802.11ac VHT40 | MCS9 | -64dBm | MCS0 | -88dBm | |
802.11ac VHT80 | MCS9 | -60dBm | MCS0 | -88dBm | |
802.11ax HE20 | MCS11 | -61dBm | MCS0 | -88dBm | |
802.11ax HE40 | MCS11 | -58dBm | MCS0 | -88dBm | |
802.11ax HE80 | MCS11 | -55dBm | MCS0 | -84dBm | |
802.11ax HE160 | MCS11 | -51dBm | MCS0 | -82dBm | |
2.4G EVM | 802.11b:≤-10 dB ；802.11g:≤-25 dB ；802.11n:≤-28dB ; 802.11ax:≤-35 dB | ||||
5G EVM | 802.11a:≤-25 dB ；802.11n:≤-28 dB ；802.11ac:≤-32 dB; 802.11ax:≤-35 dB | ||||
Frequency offset (ppm) | ±20ppm | ||||
Reset/factory restore | Supports reset button (hold 6–10 seconds for factory reset) | ||||
指示灯 | WAN LED, SYS LED, LAN port LED, 5.8G LED, 2.4G LED | ||||
Protection rating | IP67 | ||||
工作温度 | -30°C ~ 55°C | ||||
存储温度 | -40°C ~ 70°C | ||||
工作湿度 | 5%–95% (non-condensing) | ||||
存储湿度 | 5%–95% (non-condensing) | ||||
最大功耗 | < 19W | ||||
ESD testing | Air discharge ±8 kV, contact discharge ±6 kV | ||||
浪涌 | Common-mode 2 kV, differential-mode 1 kV | ||||
重量 | 1.2kg | ||||
Table 2 Software Features
首页 | Operating mode: Fat AP mode and Fit AP mode |
| 无线AP download rate, wireless AP upload rate, uptime | |
设备信息，设备描述，内网信息，WIFI信息 | |
Supported modes | Gateway mode: device connects to WAN via static IP, DHCP, or PPPoE for Internet access |
AP mode: device provides wireless coverage to clients and connects via Ethernet to another router for WAN access | |
无线功能 | SSID broadcast |
SSID count: 4 (2.4 GHz) + 4 (5 GHz), Chinese SSIDs supported | |
Hidden SSID | |
Wireless encryption: OPEN, WPA/WPA2-PSK-TKIP/AES、WPA3PSK-AES | |
Wireless MAC filtering: whitelist supported | |
Band steering (5 GHz preferred) | |
Wi-Fi scheduled shutdown | |
Client isolation: inter-SSID and intra-AP isolation | |
Transmit power settings | |
Wireless client limit | |
QoS：WMM | |
Network features | Connection: static address, from management server, or from gateway |
DHCP server: built-in or external DHCP server | |
Cloud platform server | |
Firewall features | |
PPPoE: supports PPPoE dial-up | |
设备管理 | Backup configuration |
Restore configuration | |
Factory reset | |
Restart includes scheduled and immediate restart | |
Firmware upgrade | |
Time management includes system display time and time synchronization | |
System log | |
Fat/Fit AP mode switching |
